Ozco Fr7v Pro Servo Üniversal Kalıpçı Freze Tezgahı
| Brand | Ozco |
|---|---|
| Model Type |
FR7V PRO |
Description
| Motor Power | Vertical: 3.75 kW, Horizontal: 3.75 kW, 400 V |
|---|---|
| Table Dimensions | 1470×370 mm |
| Table Load Capacity (max.) | 400 kg |
| X-Axis Movement | 1120 mm |
| Y-Axis Movement | 500 mm |
| Z-Axis Movement | 440 mm |
| T Slot Dimensions | 3×18 mm |
| Spindle Connection | Vertical: ISO40, Horizontal: ISO40 |
| Spindle Speed | Vertical: 60-3600 (variable), Horizontal: 60-1800 rpm |
| Gear | Vertical: Variable, Horizontal: 9 |
| Quill Movement | 140 mm |
| Head Rotation Angle | ±45° |
| Spindle-Table Distance | Vertical: 85-505 mm, Horizontal: 25-395 mm |
| Table Feed | X, Y: 750 W servo motor, Z: 750 W rapid motor |
| Machine Dimensions (WxDxH) | 2070x2050x2600 rpm |
| Net Weight | 2700 kg |
- Variable speed adjustment
- X and Y axis with ball screw-Japanese origin
- Yaskawa brand servo motor automatic
- Z-axis rapid motor-automatic
- Height-adjustable safety swivel guard
- Schneider electrical system
- Turcite-B coated slides
- Lighting
- Cooling system
- Chip tank
- Compliant with CE norms
- MADE IN TAIWAN
