Ozco FW110L Boring Machine Table
| Brand | Ozco |
|---|---|
| Model Type |
FW110L |
Description
| Motor Power | 7.5 KW |
|---|---|
| Spindle Diameter | 110 mm |
| Spindle Taper | ISO 50 |
| Spindle Speed | 9-1000 rpm |
| Longitudinal Table Travel (X) | 1600 mm |
| Transversal Table Travel (Y) | 1400 mm |
| Vertical Headstock Travel (Z) | 1400 mm |
| Table Dimensions | 1200×1100 mm |
| Table Load Capacity | 4,000 kg |
| T Slot Dimensions and Number | 22 mm / 7 |
| Machine Dimensions (WxDxH) | 5215x3500x3300 rpm |
| Weight | 19,600 kg |
- High quality casting
- Strong body, rigid structure
- Special bed system that expands Y-axis movement
- High quality spindle bearings
- Special spindle made of high-quality steel alloy
- User-friendly ergonomic control panel
- Automatic lubrication
- Cooling system
