Ozco Fx200 Servo Koç Kafa Freze Tezgahı
| Brand | Ozco |
|---|---|
| Model Type |
FX200 Servo |
Description
| Motor Power | Vertical: 4 kW, Horizontal: 5.5 kW 400 V |
|---|---|
| Cooling Pump Power | 90 w |
| Table Dimensions | 1600×360 mm |
| Table Load Capacity (max.) | 400 kg |
| X-Axis Movement | 1300 mm |
| Y-Axis Movement | 300 mm |
| Z-Axis Movement | 400 mm |
| T Slot Dimensions | 3×18 mm |
| Spindle Connection | Vertical: ISO50, Horizontal: ISO50 |
| Spindle Speed | Vertical: 60-1750, Horizontal: 60-1800 rpm |
| Speed Level | Vertical: 12, Horizontal: 12 |
| Head Rotation Angle | ±360° |
| Spindle-Table Distance | Vertical: 190-590, Horizontal: 20-420 mm |
| Spindle-Column Distance | 380-930 mm |
| Table Tilt | ±35° |
| Table Feed | X: 30-750 mm/min, Y: 20-500 mm/min, Z: 15-375 mm/min |
| Table Rapid Feed | X: 1200 mm/min, Y: 800 mm/min, Z: 600 mm/min |
| Table Feed Motor | 10 N.m (Servo) |
| RAM Movement | 550 mm |
| Machine Dimensions (WxDxH) | 2000x2100x2000 rpm |
| Net Weight | 2900 kg |
- 3-axis servo motor-automatic
- 3-axis digital coordinate reader
- Adjustable height safety
- Lubricated screen
- Control panel
- Automatic lubrication
- Cooling system
- Lighting
- Chip reservoir
- Compliant with CE standards
