Roll Baler Machine 155×120 Cm Haşbaylı
| Brand | New Holland |
|---|---|
| Model Type |
BR155 RC |
Cylindrical Baler Machine 155×120 cm Fixed Chamber
Economical and efficient
New Holland BR100 series; It will be the choice of bale contractors with its wide product range, low tractor power requirement and trouble-free structure.
Finger type feeding system (17 units) in 120 S and 150 S models, rotor system (in other models)155).
Read adjustable check
Suitable for all types of tractors with adjustable drawbar.
bale room
120S / 150S: 34/41 bars arranged on the chain, 155F/155RC:7 large rollers and 29 bars.
hashbay system
155RCEffective meat grinding system with the 14-knife hashbay feature in its model.
Density adjustment
User-friendly, trouble-free use with 3-stage mechanical intensity adjustment system.
usage maintenance
Ease of use and maintenance with wide opening covers.
lubrication system
Possibility to lubricate the chains with the lubrication system offered as standard
Hydraulic power requirement
120S / 150S 2 pcs,155Suitability for all types of tractors with 3 hydraulic power outputs in the model.
Motion transmission system protection
155Maximum protection is provided in the possible pick-up models with a special clutch system with a resistance of 1700 Nm.
Long lifetime
155RF andRCLong service life is ensured with greasable roller bearings in the models.
| BR155 RC | |
|---|---|
| Bale Size | 155x120cm |
| Feeding System | with rotor |
| Hashbay | Hasbayli |
| Power Requirement | 100 |
| Bale Dimensions (Diameter – Length) |
| BR120 Utility | BR150 Utility | BR155 RF | BR155 RC |
| 120 x 120 (cm) | 150 x 120 (cm) | 155 x 120 (cm) | 155 x 120 (cm) |
| Min. Tractor Power Requirement |
| PTO Speed |
| Hydraulic Connection |
| BR120 Utility | BR150 Utility | BR155 RF | BR155 RC |
| 55 (HP) | 65 (HP) | 85 (HP) | 100 (HP) |
| 540 (rpm) | 540 (rpm) | 540 (rpm) | 540 (rpm) |
| 2 x SA | 2 x SA | 2 x SA | 3 x SA |
| Winding System |
| Control Unit |
| Bale Room Dimensions |
| Bale Chamber Type |
| Number of Bale Room Lams |
| Bale Chamber Roller |
| BR120 Utility | BR150 Utility | BR155 RF | BR155 RC |
| Net | Net | Net | Net |
| Electronic | Electronic | Automatic | Automatic |
| Still | Still | Still | Still |
| Lama and Chained | Lama and Chained | Lama and Chained | Lama and Chained |
| 34 | 41 | 29 | 29 |
| 1 (piece) | 1 (piece) | 2 (pcs) | 2 (pcs) |
| Automatic Chain Lubrication |
| Maintenance Ladder |
| BR120 Utility | BR150 Utility | BR155 RF | BR155 RC |
| Standard | Standard | Standard | Standard |
| optional | optional | Standard | Standard |
| Tire Sizes |
| Machine Dimensions (Width) |
| Machine Height (max) |
| BR120 Utility | BR150 Utility | BR155 RF | BR155 RC |
| [ PHONE HIDDEN ] | [ PHONE HIDDEN ] | [ PHONE HIDDEN ] | [ PHONE HIDDEN ] |
| 215/244(cm) | 219/244(cm) | 219/258(cm) | 219/258(cm) |
| 200 (cm) | 235 (cm) | 245 (cm) | 245 (cm) |
