Single-Sided Automatic Labeling Machine

Single-Sided Automatic Labeling Machine

Our machine’s modular structure provides adjustment and ease of use according to different products. Each group is controlled by independent speed-adjustable asynchronous motors.

Encoding unit to print information such as production date/serial number, transparent label reading sensor, product feeding and collecting rotary tray, are optional accessories that can be adapted to the labeling machine.

Technical Specifications

✓ OGEM Single《E System》Single-sided labeling machine is automatic.
✓ Construction: All surfaces are stainless AISI 316 / 304
✓ Conveyor: Can vary according to demand, standard is 82 mm PVC Pallet, ~ 3,500 mm
✓ Conveyor Height: Standard 750mm (±50mm)
✓ Packaging: Glass, Plastic, PET, PE, Metal
✓ Packaging Width/Diameter: 20mm-130mm
✓ Module: 1 piece (Right and Left) Germany Herma brand (Italian brand and our own production Turkish brand can be used if desired.)
✓ Module Speed: 30m/min
✓ Module Control: SERVO Motor
✓ Label: Self-adhesive label (sticker)
✓ Label Height: 20mm-150mm / 20mm-230mm
✓ Stepless speed adjustable packaging distance opener
✓ Stepless speed and width adjustable packaging corrector
✓ Stepless speed adjustable top printing band
✓ Stepless speed adjustable round surface printing band
✓ X-Y-Z axis (three directions) adjustable labeling module
✓ Stops when the label is finished
✓ Single module operation capability
✓ Ease of maintenance and service
✓ Machine Dimensions: Width: 1300 Length: 1300 Height: 550

OGEM 《E System》Single

Areas of Use

• Food and Beverage
• Cosmetics
• Chemistry and Cosmetics
• Detergent (chemistry)
• Health
• Automotive
• Jam
• Ketchup
• Mayonnaise
• Spices
• Fruit Juices
• Honey
• Motor Oil
• Paint
