Stainless Steel Reactor
| Brand | Prosmak |
|---|---|
| Model Type |
PRS-5 |
Description
Our company manufactures high-quality stainless steel reactors for various industries, including chemical, pharmaceutical, cosmetic, food, and paint industries.
Our reactors, designed for specific needs, ensure process safety and efficiency at the highest level.
Our reactors offer high resistance, hygienic structure, long life, and process efficiency. Volume, mixer type, pressure, and temperature values can be customized according to demand.
Technical Options
- Volume Range: Production from 50 liters to 30,000 liters
- Material Options: AISI 304 / 316L, internal surface Ra ≤ 0.4 µm polish for food and pharmaceutical applications
- Mixer Types: Anchor, Turbine, Propeller, Helix, Paddle type,
- Mixing Motor: Geared motor, frequency-controlled, ex-proof, top/side/bottom drive, torque-controlled systems
- Heating/Cooling System: Heating with oil, steam, or water, jacketed or coiled system, heat-insulated outer coating
- Pressure and Vacuum: Working range -1 bar to +10 bar, pressure-resistant body and safety equipment
- Automation and Control: Manual or PLC control, temperature/pressure/level control, HMI panel, remote monitoring option
- Connections and Hardware: Tri-clamp connection, CIP/SIP line, level indicator, sample valve, manhole, observation glass
Contact us for detailed technical drawings and price quotes.
