Tcp Communication 16-Channel Digital Output Card
| Brand | Vipnet Elektronik |
|---|---|
| Model Type |
VPE-DHO-01 |
Description
• Can be integrated into all devices used in industrial environments.
• It is a special card designed to ensure the electrical integration of its systems into the factory, reduce product cost, size, provide easy assembly with an original design and eliminate cable clutter.
• Digital Output modules provide an economical and easy way to connect outputs to a Modbus TCP communication network.
• Each module operates as an independent Modbus TCP server.
• It has channels completely isolated for noise-sensitive applications.
• The Digital Output Module has 16 isolated outputs, (1) Ethernet (RJ45) connection point, Modbus TCP server, and requires external 24 VDC power.
• It is a special card designed to ensure the electrical integration of its systems into the factory, reduce product cost, size, provide easy assembly with an original design and eliminate cable clutter.
• Digital Output modules provide an economical and easy way to connect outputs to a Modbus TCP communication network.
• Each module operates as an independent Modbus TCP server.
• It has channels completely isolated for noise-sensitive applications.
• The Digital Output Module has 16 isolated outputs, (1) Ethernet (RJ45) connection point, Modbus TCP server, and requires external 24 VDC power.
Technical Specifications
Operating Voltage: 24V DC
Input Voltage: 24V DC
Output Pin Socket: 3.81mm Screw Terminal
Output Pin count: 16
Communication Type: Modbus TCP
Nominal Wiring Cross-Section Area: 2.5 mm²
Operating Temperature: -40 °C / 80 °C
Protection Element: SMD Fuse (1A)
Input Signal Tracking: LED
Mounting Type: DIN-Rail Mounting
Input Voltage: 24V DC
Output Pin Socket: 3.81mm Screw Terminal
Output Pin count: 16
Communication Type: Modbus TCP
Nominal Wiring Cross-Section Area: 2.5 mm²
Operating Temperature: -40 °C / 80 °C
Protection Element: SMD Fuse (1A)
Input Signal Tracking: LED
Mounting Type: DIN-Rail Mounting
