- Sandwich panels are used.
- Insulation thickness is 16 cm.
- Insulation material is provided with 60 kg/m³ 5 cm thickness rock wool.
- Insulation material is provided with 24 kg/m³ glass wool.
- Circulation is provided with radial fan.
- Homogeneous heat distribution is provided in the oven.
- The oven is thermoblocked and made of 310 quality stainless steel.
- Thermoblock pipes are seamless steel pull smoke pipes.
- Oven burner is approved by İGDAŞ and guaranteed by TSE.
- Exhaust fan is available in the oven.
- By placing an air curtain at the oven entrance and exit, leaks are minimized.
- Adjustable according to the size of the piece to be painted with the sliding door at the oven entrance and exit, heat leaks are minimized.
- SIEMENS and TELEMEKANIK materials are used in the oven electrical panel.
- The outer part of the oven is painted with electrostatic powder paint. Ral 5015 and 7032
- Requests other than standard sizes are evaluated separately.
- The oven sheet thickness is 1.2 mm.
|
