Top Loading Mobile Tank
| Brand | ErichHahn |
|---|---|
| Model Type |
MT-50M |
ErichHahn MT mobile tanks are designed to actively heat and store heavy oil while maintaining their quality during transportation. Mobile tanks can also be used as process tanks in oil, gas, chemical, food, and other industries. They occupy a small area and can be easily transported by road.
ErichHahn MT Advantages
The MT-М series tanks are equipped with a mixer, instrumentation, control panel, heating system, insulation, and service platforms.
Product Range
- MT-50
- MT-50М
- MT-100
- MT-100М
Control Cabin
The tank is provided with a local control cabin. This cabin allows monitoring and controlling the instrumentation on-site or remote control can be provided by integrating the cabin into the APCS.
Mobile Tank Options
• Electric heaters to increase product temperature
• Electric actuator operated covers for remote process control
ErichHahn MT-50M Technical Specifications
|
Instrumentation |
|
|
Operating environment |
Viscous and solidifying fluids |
|
Max. temperature of operating environment, °C |
200 |
|
Tank capacity, m³ |
50 |
|
Internal diameter, mm |
2105 |
|
Height, mm |
13700 |
|
Weight, kg |
8500 |
|
Tank loading type |
Top |
|
Tank unloading type |
Bottom |
|
Overflow protection device |
Provided |
|
Mixer |
|
|
Vertical |
Provided |
|
Steel structure parameters |
|
|
Number of tank courses |
9 |
|
1-2. course thickness, mm |
8 |
|
3-4. course thickness, mm |
6 |
|
5-11. course thickness, mm |
5 |
|
Roof covering thickness, mm |
5 |
|
Base thickness, mm |
10 |
|
Insulation |
|
|
Wall insulation thickness, mm |
150 |
|
Roof insulation thickness, mm |
200 |
|
Coating material |
Polimer coated steel sheet |
|
Heating system |
|
|
Main heating |
|
|
Oil heater |
Provided |
|
Heat transfer fluid |
Hot oil |
|
Oil pipe connection, mm |
50 |
|
Maximum oil temperature at 0.6 MPa, °C |
200 |
|
Additional heating |
|
|
Heating elements |
– |
|
Level gauge |
Provided |
|
Maximum level alarm |
Provided |
|
Sampling device |
Provided |
|
Temperature gauge (for heavy oil) |
Provided |
|
Electric actuated cover valve, DN, mm |
100 (optional) |
|
Bimetal thermometer |
Provided |
|
Ventilation pipe |
Provided |
|
Control panel |
Provided |
|
Country of origin |
Turkey |
