XM70 Automatic Hardness Testing Device

Axiotek XM70 Automatic Hardness Testing Device

Developed in collaboration with leading heat treatment companies; therefore, it is particularly suitable for testing tempering, nitriding, surface hardening (CHD), and coating processes.

As a result of such active collaboration, the XM70 automatic hardness testing device is designed for the following purposes:

Perform single and multiple tests on all ferrous and non-ferrous materials such as aluminum, steel, cast iron, and alloys.
Comply with all international reference standards in every detail, including ISO 6506, ISO 6507, ISO 4545, ASTM E10, ASTM E92, ASTM E384, for conducting Vickers tests (micro and macro) as well as Knoop and Brinell hardness tests.
In the most advanced version, there are also state-of-the-art product accessories, including a specially designed optical system that contains a laser and a panoramic lens. The Vickers XM70 hardness testing device can also interface with anthropomorphic robots for automatic processing of test samples.

The Vickers hardness testing device with excellent performance;
-Automatic focusing and hardness calculation
-6-position motorized turret Z-axis customizable with your selected lenses and indenters
-Manual movement of the test sample or through XY tables with 1 µm resolution
-Advanced lens focusing system for accurate Vickers test cycles even in vibration conditions
-Patented L.I.S.A Laser Centering System (Laser Indicator System Axiotek)
-Measurable force range: 10gf to 50kgf
-Automatic hardness testing device configurable in 3 different resolutions
With this configuration, the XM70 can perform Vickers test cycles even under challenging conditions.
