Yunnan Cb6650 Digital Universal Lathe

YUNNAN CB6650 Universal Lathe

YUNNAN CB6650 Universal Lathe Capacity

It has a processing capacity of 660 mm on the bed, 430 mm on the carriage, and 870 mm in the bridge clearance. The spindle bore is 105 mm, and the distance between centers is 5000 mm.

Included in the Shipment of YUNNAN CB6650 Universal Lathe

Digital coordinate reader, 3-jaw chuck Ø 250 mm, 4-jaw chuck Ø 400 mm, Plain chuck 630 mm, Fixed rest 130-260 mm, Travelling rest 20-80 mm, MK5 rotating center, MK5 fixed center, Thread clock, 4-way tool post, Halogen lamp, Change gears, Foot brake, Cooling system, Toolbox included.

General Features of YUNNAN CB6650 Universal Lathe

Compliant with CE standards, Mechanical clutch system, Emergency stop button, Safety chuck guard, Joystick for easy movement, Schneider electrical system, Cooling system and foot brake, Chuck and tool post guard.

Technical Specifications of YUNNAN CB6650 Universal Lathe

Motor Power 11 kW, 400 V w

Bed Diameter 660 mm

Carriage Diameter 430 mm

Bed Width 390 mm

Distance Between Centers 5000 mm

Maximum Material Capacity with Chuck 350 kg, with Chuck+Travelling Rest 450 kg

Speed 6-1120 rpm

Gears 24

Spindle Taper 1:20

Spindle Nose D8

Spindle Diameter 105 mm

Cross Slide Travel 360 mm

Top Slide Travel 200 mm

Travelling Rest Taper MK5

Travelling Rest Diameter 75 mm

Travelling Rest Travel 150 mm

Linear Feed [ PHONE HIDDEN ] mm/rev

Cross Feed [ PHONE HIDDEN ] mm/rev

Metric Threads and Range 1-224 (46 threads)

Inch Threads and Range 28/1-8 TPI (42 threads)

Module Threads and Range [ PHONE HIDDEN ] threads)

Diametrical Threads and Range 56-1/4 DP (45 threads)

Tool Post Size 25×25 mm

Machine Dimensions (WxDxH) 6500x1250x1400 mm

Packaging Dimensions 6770x1120x1940 mm

Weight 4700 kg

Gross Weight 5400 kg
