ZS4125 (M24) Drill & Guide Pulling Machine
| Brand | Ko-Way |
|---|---|
| Model Type |
ZS4125 |
Description
| Max. Drilling Capacity | : 25 mm |
| Max. Casting Guide Capacity | : 24 mm |
| Max. Steel Guide Capacity | : 20 mm |
| Column Height | : 85 mm |
| Spindle Stroke | : 125 mm |
| Distance Between Spindle Nose and Column | : 240 mm |
| Distance Between Spindle Nose and Table | : 367 mm |
| Max. Distance Between Spindle Nose and Base | : 630 mm |
| Spindle Taper | : MT3 |
| Spindle Speed | : [ PHONE HIDDEN ] rpm/min |
| Spindle Speed Levels | : 5 |
| Working Table Size | : 280 x 300 mm |
| Total Height | : 1127 mm |
| Motor Power | : 1.1 kW |
| Gross Weight / Net Weight | : 165 / 140 kg |
