250 Ton H Type Double Tie Rod Eccentric Press

H Type Eccentric Press – CEHP 250 Tons

Standard Features

• Steel construction body

• Pneumatic clutch – brake system

• T channel additional mounting plate

• 8 bedded ram

• Adjustable stroke on single crank arm

• Balanced piston on ram

• Full automatic thin oil lubrication system

• PLC control system

• Grand piano type control panel

• Touchscreen LCD display

• Motor reverse movement

• Overload hydraulic fuse

• Motorized ram adjustment mechanism

• Photoelectric safety curtain

• Gear group in closed oil tank

• Double coil safety valve

• Conformity to CE standards

Optional Features

• Press feeding systems

• Waste material discharge systems

• Sliding safety cover in front of the table

• Mold with desired features

Technical Features

• Steel construction 8 slideways monoblock body

• Vibration stress relief on body and welded parts

• Moving table available area: 2000 × 1100 mm

• Fixed table available area: 2000 × 1100 mm

• Parallelism and perpendicularity tolerances compliant with ISO and DIN norms

• Stroke distance: 200 mm (fixed)

• Table – Ram distance (max.): 500 mm

• Ram adjustment (regulation): 120 mm

• Eccentric shafts: 40Cr

• Gears: Cast steel

• Motorized table – ram distance adjustment

• Approximate press height: 4600 mm

• Approximate press width: 2900 mm

• Approximate press depth: 2650 mm

• Press bed height from ground: 900 mm

• Distance between walls: 2130 mm

• Press side window size adjustable as requested

• Flywheel bearing structure

• Slide bearing: Bronze (Zr14)

• Connecting rods, intermediate and main bearings: Bronze (Zr14)

• Central automatic grease lubrication

• Double crank structure

• Pneumatic clutch and brake combined system (OMPI)

• 4 pieces of ram cushioning cylinders

• Approximate press weight: 38,000 kg

Automation and Electrical Information

• Main motor: 37 kW – IE3

• Touch panel and PLC: Delta

• PLC program for adapting the mold to the press

• Speed control device: Delta

• Operating speed: 25 – 45 strokes/min

• Mold recipe capacity: 100 pieces

• Switchgear components: Siemens & Schneider

• Grand piano type or wall type electrical panel

• Table – ram distance measurement can be monitored from the screen

Production Information

This machine is manufactured by CronossTech in Turkey.
