300 Ton H Type Double Tie Rod Eccentric Press

H Type Eccentric Press – CEHP 300 Tons

Standard Features

• Steel construction body

• Pneumatic clutch – brake system

• T channel additional slide plate

• 8-bedded ram

• Adjustable stroke on single crank arm

• Counterbalance piston on ram

• Fully automatic thin oil lubrication system

• PLC control system

• Piano type control panel

• Touchscreen LCD display

• Motor reverse movement

• Overload hydraulic fuse

• Motorized ram adjustment mechanism

• Photoelectric safety curtain

• Gear group in closed oil tank

• Dual-coil safety valve

• Compliance with CE standards

Optional Features

• Press feeding systems

• Waste material unloading systems

• Sliding safety cover in front of the table

• Mold with desired features

Technical Specifications

• Steel construction 8-slide monoblock body

• Vibration stress relief in body and welded parts

• Usable area with moving table: 2000 × 1200 mm

• Usable area with fixed table: 2000 × 1200 mm

• Parallelism and perpendicularity tolerances compliant with ISO and DIN standards

• Stroke distance: 200 mm (fixed)

• Table – Ram distance (max.): 500 mm

• Ram adjustment (adjustment): 120 mm

• Eccentric shafts: Ç4141

• Gears: Cast steel

• Motor-adjusted table-ram distance

• Approximate press height: 4700 mm

• Approximate press width: 2900 mm

• Approximate press depth: 2750 mm

• Press lower table height from floor: 900 mm

• Distance between walls: 1230 mm

• Window size on press side can be adjusted as desired

• Flywheel bearing structure

• Slide bearings: Bronze (Zr14)

• Connecting rods, intermediate and main bearings: Bronze (Zr14)

• Central automatic grease lubrication

• Double crank structure

• Pneumatic clutch and brake combined system (OMPI)

• 4 ram cushion cylinders

• Approximate press weight: 41,000 kg

Automation and Electrical Information

• Main motor: 45 kW – IE3

• Touch panel and PLC: Delta

• PLC program for adapting mold to press

• Speed control device: Delta

• Operating speed: 25 – 45 pcs/min

• Mold recipe capacity: 100 pcs

• Switchgear: Siemens & Schneider

• Piano type or wall type electrical panel

• Measurement of table-ram distance can be monitored on screen

Production Information

This machine is manufactured by CronossTech in Turkey.
