ErichHahn MT-50 Industrial Mobile Tank

ErichHahn MT mobile tanks are designed to actively heat and store heavy oil while maintaining its quality during transportation. Mobile tanks can also be used as process tanks in the oil, gas, chemical, food, and other industries. They are compact and can be easily transported by road.

ErichHahn MT Advantages

MT-M series tanks are equipped with a mixer, instrumentation, control panel, heating system, insulation, and service platforms.

Product Range

MT-50
MT-50M
MT-100
MT-100M

Control Cabin

The tank is provided with a local control cabin. This cabin allows monitoring and controlling the instrumentation on-site or remote control can be provided by integrating the cabin into the APCS.

Mobile Tank Options

• Electric heaters to increase product temperature
• Electric actuated covers for remote process control

Technical Specifications of ErichHahn MT-50

Instrumentation
Operating Environment	Viscous and solidifying liquids
Max. Temperature of Operating Environment, °C	200
Tank Capacity, m³	50
Inner Diameter, mm	2105
Height, mm	13700
Weight, kg	8500
Tank Loading Type	Top
Tank Unloading Type	Bottom
Overflow Protection Device	Provided
Mixer
Vertical	–
Steel Structure Parameters
Number of Tank Courses	9
1-2. Course Thickness, mm	8
3-4. Course Thickness, mm	6
5-11. Course Thickness, mm	5
Roof Coating Thickness, mm	5
Base Thickness, mm	10
Insulation
Wall Insulation Thickness, mm	150
Roof Insulation Thickness, mm	200
Coating Material	Polymer coated steel sheet
Heating System
Main Heating
Oil Heater	Provided
Heat Transfer Fluid	Hot oil
Oil Pipe Connection, mm	50
Max. Oil Temperature at 0.6 MPa, °C	200
Additional Heating
Heating Elements	–
Level Gauge	Provided
Max Level Alarm	Provided
Sample Taking Device	Provided
Temperature Gauge (for heavy oil)	Provided
Electric Actuated Cover Valve, DN, mm	100 (optional)
Bimetal Thermometer	Provided
Ventilation Pipe	Provided
Control Panel	Provided
Country of Origin	Turkey

Brand	ErichHahn
Model Type	MT-50
